Dimension: Ø 18 x 83 mm

Style Housing: M18x1

Installation: non-flush

Range: 1.25…8 mm

Analog output: Analog, current 2.3…8.5 mA

Output characteristic: falling on approach

Repeat accuracy per BWN: ±2.0 µm

Housing material: Brass, nickel plated

Material sensing surface: PA 12

Connection: Cable, 5.00 m, PVC

Operating voltage Ub: 10…30 VDC

Ambient temperature: -10…60 °C

IP rating: IP67

Approval/Conformity: CE

                                   EAC

                                   WEEE

>>>Datasheet_BAW0005_517882_en
