| Dimension | Ø 6.5 x 45 mm |
| Style Housing | D6.5 |
| Installation | for flush mounting |
| Range | 0.5…2 mm |
| Analog output |
Analog, voltage 0…10 V
|
| Output characteristic | falling on approach |
| Limit frequency –3 dB | 1000 Hz |
| Repeat accuracy per BWN | ±40 µm |
| Non-linearity max | ±45 µm |
| Housing material | Stainless steel |
| Material sensing surface | PBT |
| Connection | Connector, M8x1-Male, 3-pin |
| Operating voltage Ub | 15…30 VDC |
| Ambient temperature | 10…60 °C |
| IP rating | IP67 |
| Approval/Conformity | CE UKCA cULus WEEE |
>>> REFER TO TECHNICAL DOCUMENT: Datasheet_BAW000L_278732_en
