Inductive sensor IF0309 IFK2004-AROA/SL/LS100-AK RT
**Product Characteristics:**
– Output function: Normally open
– Sensing range [mm]: 4
– Housing: Threaded type
– Dimensions [mm]: M12 x 1
**Electrical Data:**
– Frequency AC [Hz]: 47…63
– Operating voltage [V]: 20…140 AC / 10…140 DC
– Protection class: I
– Reverse polarity protection: No
**Outputs:**
– Output function: Normally open
– Max. voltage drop switching output DC [V]: 5
– Max. voltage drop switching output AC [V]: 5
– Minimum load current [mA]: 5
– Max. leakage current [mA]: 0.8
– Permanent current rating of switching output AC [mA]: 200
– Permanent current rating of switching output DC [mA]: 200
– Short-time current rating of switching output [mA]: 900; (20 ms / 0.5 Hz)
– Switching frequency AC [Hz]: 25
– Switching frequency DC [Hz]: 90
– Short-circuit proof: No
– Overload protection: No
**Monitoring Range:**
– Sensing range [mm]: 4
– Real sensing range Sr [mm]: 4 ± 10%
– Operating distance [mm]: 0…3.25
**Accuracy / Deviations:**
– Correction factor: Steel: 1 / Stainless steel: 0.7 / Brass: 0.45 / Aluminum: 0.4 / Copper: 0.33
– Hysteresis [% of Sr]: 3…15
– Switch-point drift [% of Sr]: -10…10
**Operating Conditions:**
– Ambient temperature [°C]: -25…70
– Protection: IP 67
>>> Refer to technical document:
