-PCD of Screw Holes or DIN 5480 Teeth No. or Internal Diameter
-Sub-Series according to Fig.
A = Fig. A
B = Fig. B
C = Fig. C
-Pinion Teeth No.
-Teeth Angle
L = Left-Hand Helical 19°31’42”
l* = Straight
-Module-No.
1∼12
The non-integer module no. will be given in alphabet.
-Series
A =Curvic Plate
B =Welded Plate
C= Teeth Plate
D= DIN 5480
E, F = Keyway
G = Long Shaft w. KW
H = Long Shaft w/o KW
COMMON CODE:
| Set | Pinion only |
| A02L17B031 | A02L17 |
| A02L20B050 | A02L20 |
| A02L20A063 | A02L20 |
| A02L20C063 | A02L20 |
| A03L18A080 | A03L18 |
| A03L18C080 | A03L18 |
| A08L15A200 | A08L15 |
>>>Refer to: Catalog Rack and Pinion
