Module-No.: 1 – 12 (The non-integer module no. will be given in alphabet.)
Quality: 4/5/5+/6/6M/8H/8/9/10
Teeth Angle: R = Right-Hand Helical 19’31″42″
I* = Straight
Rack Length: Rack Length x 0.1 (in mm)
Material: C = Carbon Steel
S = Stainless Steel
Q = Q&T Alloy Steel
Screw Holes: 1* = Standard
0 = Without Screw Holes
S/X = Strong
Coating: 0 = None
N = Nickel Plating
P = Phosphate Film
B = Blackening
MỘT SỐ MÃ THÔNG DỤNG:
0205R125C10
2J05R175C10
0305R125C10
0405R100CS0
0605R100C10
1005R100C10
1205R100C10
0405R100CX0
>>>Refer to: Catalog Rack and Pinion
