Dimension: Ø 12 x 65 mm
Style Housing: M12x1
Installation: non-flush
Range: 1…4 mm
Analog output: Analog, voltage 0…10 V
Output characteristic: falling on approach
Limit frequency –3 dB: 500 Hz
Repeat accuracy: ±10 µm
Non-linearity max.: ±90 µm
Housing material: Brass, nickel-plated
Material sensing surface: PBT
Connection: Cable, 3.00 m, PUR
Operating voltage Ub: 15…30 VDC
Ambient temperature: -10…70 °C
IP rating: IP67
Approval/Conformity: CE
UKCA
cULus
WEEE
