All Industrial PCs can be equipped with a 24 V power supply unit and an integrated UPS. The UPS supplies the PC with power if the mains power fails. This allows data to be saved on the hard disk or Flash, after which the PC can be shut down properly. A battery pack, which serves as the energy storage device, is mounted on a DIN rail outside the PC.
Rated at 3.4 Ah, the maintenance-free C9900-U330 24 V battery pack offers a very high nominal capacity in a compact package.
Product information:
| Technical data | C9900-U330 |
| Type | battery pack for PCs with 24 V power supply with intergrated UPS, 3.4 Ah |
| Housing | metal housing for mounting on norm rail TS35x15 2.3 |
| Nominal capacity | 3.4 Ah (20 h discharge) |
| Nominal voltage | 24 V |
| Internal structure | two 12 V batteries in series connection |
| Fuse | 9 A by PTC element |
| Dimensions (W x H x D) | 157 mm x 70 mm x 175 mm |
| Weight | 3.3 kg |
| Operating temperature | 0…+50°C |
| Additional information | VRLA AGM Technology = valve regulated lead acid batteries with glass fiber mat inside the separator (VRLA = valve regulated lead acid, AGM = absorbed glass mat technology) |
>>> REFER TO TECHNICAL DOCUMENT: C9900-U330en
