KL9200 | Potential supply terminal, 24 V DC, with fuse

KL9200 | Potential supply terminal, 24 V DC, with fuse

The KL9200 power feed terminal makes it possible to set up various potential groups with the standard voltage of 24 V DC.

Current load ≤ 10 A

Integrated fine-wire fuse …6.3 A

Power LED green

Defect LED red

Diagnostics –

Current consumption K-bus –

Nominal voltage 24 V DC

Electrical isolation yes

Reported to K-bus –

PE contact yes

Shield connection –

Renewed infeed –

Connection facility to additional power contact 1

K-bus, looped through yes

Bit width in the process image 0

Electrical connection to DIN rail –

Housing width 12 mm

Special features integrated fuse

Weight approx. 50 g

Side by side mounting on Bus Terminals with power contact yes

Side by side mounting on Bus Terminals without power contact yes

Operating/storage temperature 0…+55 °C/-25…+85 °C

Approvals/markings CE, UL, ATEX, IECEx, DNV GL

Ex marking ATEX:

II 3 G Ex nA IIC T4 Gc

IECEx:

Ex ec IIC T4 Gc

>>> Refer to technical document:kl91xx_kl92xxen
