CX2072 | Basic CPU module

Contact

BRAND: BECKHOFF

PRODUCT CODE:CX2072

CATEGORY: PLC BECKHOFF

SUPPLIER: SUNLY

Description
Reviews (0)

The CX2072 features an Intel ® Xeon ® CPU with a clock speed of 2.1 GHz (12 cores). A fan with ball bearings and speed monitoring is integrated into the base CPU module. In addition to the CPU, the basic module also contains main memory with a RAM size of 8 GB, options are available with up to 64 GB. The controller boots from a CFast flash memory card where both the operating system as well as programs and user data are stored.

The CPU has an internal 128 kB NOVRAM, which acts as a persistent data memory if a UPS is not used.

Using TwinCAT 3 allows automation tasks to be distributed across different cores of the Intel ® Xeon ® CPU .

All system modules from the CX2000 series for left or right function extensions can be connected. Internally, the modules are connected via PCI Express and can be plugged into the CPU in the field.

Power for the CPU module comes from the CX2100-0014 power supply module. Up to two mass storage modules (CX2550-0010 CFast module or CX2550-0020 2½-inch SSD module) can be inserted between the power supply and CPU, allowing up to three devices to be used in total. bag

Specifications	CX2072
Processor	Intel ® Xeon ® D-1567 2,1 GHz
Number of cores	12
Graphics	AMD E8860, 2GB GDDR5
Flash memory	CFast card slot, card not included
Main memory	8 GB DDR4 RAM (expandable to 64 GB)
Persistent memory	Integrated 128 kB NOVRAM
Display	2 x RJ45 10/100/1000 Mbit/s, 1 x DVI-I, 4 x USB 3.0, 1 x optional interface
cooling	Integrated fan with bearings and speed monitoring
Diagnostic LED light	1 x power, 1 x TC status, 1 x flash access, 2 x bus status
Clock	watch supports internal battery for date and time (battery can be replaced)
Operating system	Windows 10 IoT Enterprise 2016 LTSB, Windows 10 IoT Enterprise 2019 LTSC, Windows 10 IoT Enterprise 2021 LTSC, TwinCAT/BSD
Control software	TwinCAT 3 runtime (XAR)
I/O connection	via power supply module (E-bus or K-bus, automatic recognition)
Power supply	24 V DC (-15%/+20%)
Max. Energy consumption	131 W
Dimensions (W x H x D)	204 mm x 99 mm x 91 mm
Weight	about 1650 grams
Relative humidity	95%, no condensation
Operating/storage temperature	-25…+50°C/-40…+85°C
EMC immunity/emission	Complies with EN 61000-6-2/EN 61000-6-4
Anti-vibration/shock	conforms to EN 60068-2-6/EN 60068-2-27
Protection rating	IP20
Approve/mark	CE, UL
TwinCAT 3 platform level	Very High Performance (81); Please see here for an overview of all TwinCAT 3 platform levels
